Direkt Gate Closer

Slider

Quick and simple to fit, the DIREKT closer doesn't require any specialist knowledge to install. The closer is surface mounted and can be installed with the gate in-situ so is ideal for retro-fitting to gates that need to be upgraded to self-closing. Appreciated for it's economy and simplicity, this is our most popular closer.

The gate closer DIREKT operates directly on the gate/door without the help of any lever. It is fixed with one end to the gate post or the door frame and with the other to the door or gate itself.

It operates similarly to a gas spring. When the gate is open, the piston rod of the gate closer is compressed and the pressure of the gas inside the gate closer acts on the piston. The piston rod extends and closes the door/gate. The cylinder of the gate closer contains hydraulic oil, which results in a controlled closing speed that is slowed down. By using nitrogen instead of a helical spring, much higher closing forces can be achieved. Thus the gate closer DIREKT always closes the door/gate reliably despite its small diameter.



Specifications

Surface mounted, Easy installation, Economical solution, For gates up to 100 Kg, Up to 110 degree opening, Hydraulic damping, Adjustable closing speed

The DIREKT gate closer is available in two sizes:

DIREKT '150' for gates up to  80Kg / 1200mm wide

DIREKT '200' for gates up to 100Kg / 1500mm wide
